Wheel Loader Light Material

Wheel Loader Light Material Bucket

McCormack Industries light material buckets are buckets suited for compact wheel loaders with operating weight up to 7500kg and medium wheel loaders with operating weight up to 20,000kg

Backed by ongoing support and service, all McCormack Industries buckets have replaceable parts to ensure longevity.

Light Material Bucket

Inclusions

McCormack Industries manufactures light material buckets (LM) for Wheel Loaders. These buckets are ideal for handling grain, bark chip, silage or manure, and come with standard features including, side and front cuttings edges with a bolt on front cutting edge.

The economical construction allows for maximum capacity and are manufactured in a range of widths and capacities up to 6m³.

Buy Once, Buy McCormack

Economical

Construction

The McCormack Industries light material buckets (LM) are quality made to outlast the life of your wheel loader.

The economical design and construction using high tensile plate, with 450 Grade wear strips on all leading edges ensures it will stand up to the most demanding earthmoving work.

Coupled with McCormack's 40 years of experience and renowned after sales service, these buckets are your best choice in the market.

Specifications

Compact Wheel Loaders - Up to 7.5t

Width	1800mm	2000mm	2200mm	2400mm	2700mm

Capacity	1.12 m3	1.25m3	1.37m3	1.50m3	1.70m3

Small & Medium Wheel Loaders - 7.5t to 20t

Width	2400mm	2700mm	3000mm

Capacity	2.00m3, 2.50m3, 3.00m3, 3.50m3, 4.00m3	2.80m3, 3.40m3, 4.00m3, 4.50m3, 5.00m3, 5.50m3	3.75m3, 4.50m3, 5.00m3, 5.50m3, 6.00m3

Weight	700-1400kg	1000-1450kg	1125-1800kg

*Engine horsepower rating is used as a guide only to selecting the appropriate bucket model. Contact McCormack Industries for confirmation on the correct bucket size
