Front End Loader 15-45hp
Widely known as the "Front End Loader People" since 1984, McCormack Industries has the widest range of Front End Loaders for new and used tractor. The FA range suits tractors ranging from 15 to 45 horse power.
Unlike some loaders on the market these loader arms are quality made and durable. Front-end loader (FEL) kits are available.
Backed by ongoing support and service, all McCormack Industries Loaders have replaceable parts to ensure the longevity of your loader and attachments.
FEL Standard
Inclusions
McCormack Industries Loaders come standard with:
- Quick Hitch
- Self-leveling
- TMA Loader standard compliance
- Diverter for 3rd function hydraulics
- 2 Bank Control Valve with joystick
- Greaseable pivot points
- Level Gauge
- Quality 4 in 1 Bucket
- Quick detach (from tractor) system
- Paint colour to match your machine's brand
- Reliable after sales support and spare parts availability
- Available as a DIY kit which can be installed onsite.
Suits 2WD or FWA agricultural tractors only
Heavy Duty
Construction
The McCormack Industries loaders are quality made to outlast the life of your tractor.
Heavy duty construction and greaseable pivot points ensures years of dependable service.
Coupled with McCormack's 40 years of experience and renowned after sales service, these loaders are your best choice in the market.
Optional soft ride system consisting of a nitrogen-filled accumulator assists in taking away vibrations on the loader during travel.
Buy Once, Buy McCormack
Quality you can trust!
FEL Specifications
| FA15 Loader | FA35 Loader | FA45 Loader | |
|---|---|---|---|
| Engine HP Range* | 15-25hp* | 25-35hp* | 35-45hp* |
| Max Lift Height (A) | 1800mm | 2315mm | 2750mm |
| Dump Clearance (B) | 1250mm | 1730mm | 2150mm |
| Max Dump Angle (C) | 50 deg. | 57 deg. | 63 deg. |
| Reach at Ground (D) | 1350mm | 1650mm | 1700mm |
| Crown Back Angle (E) | 30 deg. | 39 deg. | 43 deg. |
| Digging depth (F) | 120mm | 140mm | 160mm |
| Heaped Capacity | 0.12m/sq | 0.27m/sq | 0.27m/sq |
| Rec. Bucket Width | 1200mm | 1400mm | 1600mm |
| Max Lift Capacity | 200kg | 250kg | 750kg |
| Max Blade / Rake Size | 1200mm | 1500mm | 1600mm |
*Engine horsepower rating is used as a guide only to selecting the appropriate loader model. Other factors including the tyre size, chassis shape and axle configuration can affect loader sizing. Contact McCormack Industries for confirmation on the correct loader size.
FEL Tractor Suitability
Front End Loader for 10-25hp Tractors
Ideal for small acreage and hobby farmers the McCormack FA15 front end loader is suited for small compact tractors less than 25HP* such as:
JOHN DEERE 2032R, 2025R, 1025R, 1023R and 2720
KUBOTA BX2230.
*SOME TRACTOR MODLES NOT AVAILABLE IN KIT FORM
Front End Loader for 25-35hp Tractors
The McCormack F35 front end loaders are best suited to small acreage and hobby farmers with small compact tractors less than 35HP* such as :
JOHN DEERE 3032E / 3032R, 3038E / 3038R, 3520, 4105, 3320, 3045R, 3120, 3036E, 2025R, 2036R, 2032R, 950, 2038E and 3039R
KUBOTA L3400, B3150HDCC, L3300, L3250, L3200, B2601, B2301, B2320, B2100, B2400, B7100HST, B7100, L3800, B6000, B2601HD, B2920, L2050 and BX2680
CASE 35
NEW HOLLAND T1520
*SOME TRACTOR MODLES NOT AVAILABLE IN KIT FORM
Front End Loader for 30-45hp Tractors
With up to 750kg capacity the McCormack FA45 Front End Loaders are perfect for small acreage and hobby farmers with small compact tractors less than 45HP* such as
JOHN DEERE 4720, 4049R, 4049M, 4066M, 4066R, 4320 compact, 5085GV' 3720, 4520 compact, 1070, 5076EN and 4066R
KUBOTA MX5100, L4400, MX5200, L4600 and L5740
MASSEY FERGUSON 35
NEW HOLAND BOOMER 50
DAEDONG DK551
*SOME TRACTOR MODLES NOT AVAILABLE IN KIT FORM
