Telehandler Light Material Bucket
McCormack Industries light material (LM) buckets are buckets suited for telehandlers and hold a larger capacity than front end loader equivalents.
Light Material Bucket
Inclusions
McCormack Light Material (LM) Telehandler buckets are larger capacity than the Front-End Loader equivalents. Similarly, they are designed especially for any light materials – grain, silage, loamy soils, compost, bark chip etc. These buckets feature economical but durable construction to maximise the carrying capacity of the machine.
We also make them with standard side cutting edges and a weld on edge along the front length of the bucket. Bolt on edges are available as an extra.
Buy Once, Buy McCormack
Light Material (LM) Bucket with Grab
Economical
Construction
The McCormack Industries light material (LM) buckets are quality made to outlast the life of your telehandler.
The economical design and construction using high tensile plate, with 450 Grade wear strips on all leading edges ensures it will stand up to the most demanding earthmoving work.
Coupled with McCormack's 40 years of experience and renowned after sales service, these buckets are your best choice in the market.
Specifications
| Width | 2400mm | 2400mm | 2400mm | 2400mm | 2400mm |
|---|---|---|---|---|---|
| Capacity | 2.00m³ | 2.50m³ | 3.00m³ | 3.50m³ | 4.00m³ |
| Depth | 900mm | 1020mm | 1200mm | 1300mm | 1500mm |
| Height | 1090mm | 1175mm | 1280mm | 1360mm | 1460mm |
| Weight | 530kg | 590kg | 800kg | 900kg | 970kg |
*Engine horsepower rating is used as a guide only to selecting the appropriate bucket model. Contact McCormack Industries for confirmation on the correct bucket size
3D Model - 360deg. View
Gallery
LM Buckets Also Available for Tractors
Prefer to use your tractor to move material? McCormack Industries also manufacture LM buckets to suit. Click link to view our range.
