3pt Linkage Blade Rake
The McCormack 3pt linkage blade rakes are available for the back of tractors, ideally to free up the front-end loader to use a 4 in 1 bucket allowing you to move between tasks quickly.
3pt Linkage Blade Rake for Tractors
Designed with a dozer blade on one side and stick rake tynes on the other side the blade rake give you 2 attachments in 1.
Use the dozer to move dirt and the stick rake to move material while leaving the ground un-disturbed. The McCormack Industries 3-point linkage blade rake is ideal for large properties.
It’s available to suit Category 2 and 3 three point linkage types in widths up to 2700mm.
3pl Blade Rake Features:
- Available with hydraulic or manually adjustable angle
- Widths available up to 2700mm
- Configuration available to suit all 3pt linkage types
- Easy connection
- Australian Made Quality
Blade Rake Accessories
Manual or Hydraulic
Angle
This is a simple accessory for all blades, blade/rakes and stick rakes. It puts the blade on an angle to make grading easier.
This product fits between one of the attachment mounts and the backing frame on one side. The other blade mount on the other side stays locked to the backing frame, thereby giving the blade an angle to the backing frame.
It can be easily removed and installed by simply removing and replacing two pins.
Blade Rake Wings
To extend the width of your blade or blade rake tipped wings can be added, these will increase the width of your attachment by an extra 1000mm, Increasing the efficiency and productivity of your operation.
These wings are also made to be removable by undoing 3 bolts each side to allow for ease of transportation.
Blade Rake Grab
Increase the functionality with any stick rake or blade/rake by adding a spear grab. The grab retracts fully out of the way for typical use, but can be lowered to grip and lift what’s been collected. Spears are replaceable if bent.
A Spear Grab addition provides a fast way to move trash across a paddock without the need of pushing it along the ground all the way to the pile.
Depth Skids
When using a blade, blade/rake or stick rake the depth of your attachment can be controlled by fitting Depth Skids.
The blade can be lowered until the depth skids contact the ground.
These have a range of holes giving 20mm incremental adjustments in depth.
3pt Linkage Grader Blade
McCormack Industries also manufactures a range of tractor grader blades which mount onto the 3pt linkage.
